wifi 6 wireless protocol is supported
equipped with 1ghz high-end chip, 256mb flash memory 128m memory
all gigabit ports enjoy gigabit network speed, 1800mbps wireless dual-band signal
mu-mimo ofdma technology, lower delay, faster speed
| model | power 20ax |
| supported standards and protocols | ieee802.11 b/g/n/ac/ax |
| port |
1个10/100/1000m auto mdi/mdix rj45 wan port |
| forwarding rate | 10/100/1000mbps |
| wireless specifications | 2.4g band: 574mbps; 5g band: 1201mbps |
| antenna | 4 high-gain omnidirectional antennas |
| cpu | 1ghz(dual core) |
| ram | 256mb（internally packaged in the main ic） |
| rom | 128mb |
| button | default×1 |
| led indicator | pwr、internet、wifi、lan1、lan2、lan3、wan |
| size | 236mm×144mm×50mm |
| power supply | 12v/1a |
| operating environment | operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
| common functions |
quick configuration |
| security |
malicious url firewall |
| basic settings |
system upgrade |
| others |
emergency recovery |
