-free of debugging, plug and play
-built-in 2*14dbi high-gain dual antennas
-support 5g network wireless band
-support up to 3km stable transmission when there are no obstacles
-support one-to-one, one-to-multiple expansion
-adapt to a variety of harsh environments
-master-slave setting, channel debugging, ip modification
| product model | nc9003 |
| wireless protocol | ieee802.11a/n /ac |
| port |
2*10/100m rj45 lan port |
| wireless band | 5.150ghz～5.850ghz |
| wireless rate | 5ghz：450mbps |
| antennas | 2*14dbi high-gain antennas |
| memory | 8mb |
| flash | 2mb |
| channel distribution |
5g：36、40、44、48、52、56、60、64、149、153、157、161、182、186、190、194 |
| frequency offset | ±20ppm |
| evm | 802.11n:≤-28db 802.11a:≤-25db |
| acceptance sensitivity |
11a:72dbm@54mbps, -90dbm@6mbps 11n:-70dbm@mcs7, -90dbm@mcs0 |
| button |
reset key (long press for 15 seconds to restore factory default settings, short press for 1 second to initiate pairing) |
| led indicator | sig， eth、power、digital tube light |
| waterproof performance | ip65 |
| poe |
poe： non-standard poe 24v/1a dc: 12v/1a power＜10w |
| size | 86mm*37mm*248mm |
| operating environment |
operating temperature: -30°c ~ 55°c storage temperature: -40°c ~ 70°c operating humidity: 10% ~ 90%, non-condensing storage humidity: 5% ~ 90%, non-condensing |
| mperation mode | master ap/slave ap dial switch |
| networking mode |
one-to-one, one-to-multiple expansion（<8 point） |
| management mode |
web |
| network settings |
bridge: automatic acquisition/static ip router: automatic acquisition/static ip/pppoe |
| bridge management | free binding cloud account, real-time remote management device |
| wireless management | bridge configuration/advanced configuration /wifi settings |
| system update | online upgrade |
