-5*10/100m adaptive rj45 ports
-follow ieee802.3 ethernet and ieee802.3u fast ethernet protocol standard
-support full-/half-duplex working mode
-plug and play, flexible adapt to various scenarios
|
product model |
ns115 |
| standard protocol | ieee802.3, ieee802.3u, ieee802.3x |
| network medium |
10base-t: cat3 or above utp 100base-tx: cat5 or above utp |
| port | 5*10/100m rj45 lan port |
| backplane bandwidth |
1gbps |
| mac address table | 2k |
| size | 100×65×22.55mm |
| led display | 10/100mbps（link/act）、power |
| forwarding mode | store and forward |
| access method | csma/cd |
| power | 5v/600ma |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
