-customized for surveillance/networking
-provide a perfect solution for the connection of ethernet and fast ethernet
-compatible with ieee 802.3 10base-t, ieee 802.3u 100base-tx, ieee802.3ab 1000base-t
-low-power circuit optimized design, energy saving and environmental protection; lightweight, beautiful design
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
.jpg)
|
product model |
ns308 |
| standard protocol | ieee 802.3 10base-t、ieee 802.3u 100base-tx、ieee 802.3ab 1000base-t |
| network medium |
10base-t: cat3 or above utp 100base-tx: cat5 or above utp 1000base-tx: cat5e or above utp |
| port | 8*10/100/1000m rj45 lan port |
| forwarding rate | 10/100/1000mbps |
| backplane bandwidth |
16gbps |
| mac address table | 2k |
| size | 148*117.5*25.3mm（l*w*h） |
| led display | 10/100mbps（link/act）、power |
| power | dc 9v/500ma |
| working environment |
operating temperature: 0°c ~ 40°c storage temperature: -20°c ~ 70°c operating humidity: 10% ~ 90%, rh non-condensing storage humidity: 5% ~ 90%, rh non-condensing |
